TIGER
Technical specifications
Minimum resolution* • 1 ppb or 0.001 mg/m3
Maximum reading** • 20,000 ppm or 20,000 mg/ m3 (gas dependent)
Response time • T90 < 2 seconds
Accuracy* • 5% display reading one digit
Linearity* • 5% display reading one digit
Intrinsically safe approvals
• II 1G Ex ia IIC T4 Ga
• Tamb = - 15 0C ≤Ta ≤+45 0C (with lithium ion battery pack)
• Tamb = - 15 0C ≤Ta ≤+45 0C (with alkaline battery pack)
• ITS09ATEX26890X IECEx ITS 10.0036X • 3193491 conforms to UL Std. 913, 61010-1 &
• Certified to CAN/CSA Std. C22.2 No. 61010-1
Battery life
• Li-ion: life up to 24 hours continual use
• Alkaline: (Duracell Procell MN 1500) life up to 8.5 hours continual use
Lamps • 10.6 eV Krypton PID lamp (standard.) 10.0 eV and 11.7 eV lamps available
Data logging* • Including date / time: 120,000 points
Communication
• Direct USB 1.1 connection Alarm
• Flashing LED and 95 dBA at 300mm (12”) audible sounder
• Selectable vibrating
alarm
• Pre-programmed TWA and STEL*
• Pre-programmed with over 700 gases*
Flow rate • 220 ml/min in ambient conditions (with blocked flow alarm)
Temperature
• Operating: -20 to 60 0C, -4 to 140 0F (non Intrinsically Safe)
• Humidity: 0-99% RH (non condensing)
Protection
• Designed to IP65 (heavy rain)
• 1180
• EMC tested to EN613261:2006, EN50270:2006 & CFR 47:2008 Class A
Weight & dimensions
• Instrument with probe
• Width: 340 x Height: 90 x Depth: 60 mm (13.4 x 3.6 x 2.4”)
• Standard case
• 367 x 89 x 90 mm (14.45 x 3.54 x 2.36”)
• Instrument weight 0.72 kg (1.56lb)
• Packed weight: 5 .5kg (12lb)
详情请电洽，皆可细谈
TIGER LT
Technical specifications
Minimum resolution* • 0.1 ppm
Maximum reading • 5,000 ppm
Response time • T90 < 2 seconds
Accuracy* • 5% display reading one digit
Linearity* • 5% display reading one digit
Intrinsically safe approvals
• II 1G Ex ia IIC T4 Ga
• Tamb = - 15 0C ≤Ta ≤+45 0C (with lithium ion battery pack)
• Tamb = - 15 0C ≤Ta ≤+40 0C (with alkaline battery pack)
• ITS09ATEX26890X IECEx ITS 10.0036X
• 3193491 conforms to UL Std. 913, 61010-1 &
• Certified to CAN/CSA Std. C22.2 No. 61010-1
Battery life • Li-ion: life up to 24 hours continual use
Lamps • 10.6 eV Krypton PID lamp (standard.)
Data logging* • Push-to-log, 128 zones, 80,000 data points
Calibration • Standard calibration 100 ppm isobutylene • Custom calibration capability
Alarm • Flashing LED and 95 dBA at 300mm (12”) audible sounder • Selectable vibrating alarm
Flow rate • 220 ml/min in ambient conditions (with blocked flow alarm)
Temperature • Operating: -20 to 60 0C, -4 to 140 0F (non-Intrinsically Safe) • Humidity: 0-99% RH (non condensing)
Protection • Designed to IP65 (heavy rain) • 1180 • EMC tested to EN613261:2006, EN50270:2006 & CFR 47:2008 Class A
Weight & dimensions • Instrument (with probe) • Width: 91.4 x Height: 370 x Depth: 61 mm (3.59 x 14.56 x 2.4”) • Instrument weight 0.75 kg
Guardian PID
维修简易‚不需工具即可取下探头模组
大型紫外线灯、提高灵敏度、反应时 间快、解析度与可靠性高
卓越的紫外线灯设计、耐用、寿命长
防爆认证
内置取样泵‚反应时间更快
湿度补偿‚读值更精准
应用范围广‚高阶机种*内建200多种
气体的修正系数
应用
炼油分析-测苯
工业应用-测氨气
化学制造-测氯乙烯
半导体业-测甲苯或氨气
造纸业-测二氧化氯、过氧化氢或臭 氧
溶剂与化学品储存
制药业-测二氧化碳、氮气、苯酚和 二甲醚
印刷业-测甲苯
空气品质监测
喷漆房-测甲乙酮
热传导液
医疗、病理学实验室-测丙酮、二甲 苯、酚
Guardian PID挥发性有机气体侦测器‚提供即时的VOC气体量测。
可分离式探头 模组‚使维修与校正更形简易。
显示面板 提供图形与数字显示、LED状态指示灯清 楚显示故障与警报状况。
此外,低警报、高警报与故障警报继电器 可用以控制外部警报装置。(高阶机种配 备*)
*1 ~ 1000ppm的基本机型不具备修正 系数与警报继电器输出。
传感器规格
工作电压: DC 10 to 28V, 210mA at 24V
消耗功率: < 5 W
类比与数位输出: 4-20 mA and RS-485
三组警报继电器输出: 30 VDC , 2A
取样方式: 内建取样泵浦, 约500cc/min
防护等级: IP65
防爆等级: Ex II 2(1)G, Ex d [ ia Ga ] IIC T4 Gb
温度: -20℃～55℃
湿度: 0-95% RH, non-condensing
压力: 90 kPa～110 kPa
尺寸: 257 x 201 x 107 mm
重量: 3.5公斤
机壳材质: 316 SS
DigiPID 探头模组规格
探头: 光离子式, PID
反应时间: 30秒
精确度: ± 2% 於校正点
耗电量: < 0.6 W
量测范围:
机型：003-0009 0.01 ~ 100 ppm, 解析度: 0.01ppm
机型：03-0010 0.1 ~ 1000 ppm, 解析度: 0.1或1ppm
机型：03-0012 1 ~1000ppm, 解析度: 1ppm
防电磁干扰 EMI/RFI: 符合EMC Directive 2004/108/EC
模组外壳材质: 316 SS
尺寸: 49 mm x 150.8 mm
重量: < 550g
防爆等级: II 1 G EX ia IIC T4 and 1M1 Ex ia I
